Multi-function Tools for Cable Termination
(Applicable for Simplex IF Drop Cables)
This multifunctional tool can perform two functions: it terminates cable ends for Simplex IF Drop Cables to remove part of the coated fiber when fixing FA and FSC connectors for field assembly and it separates the suspension wire from the new type of drop cable.
[Product code]
P2681011
Specifications
| Cables | Dimensions | Weight (g) |
|---|---|---|
| 1SM-IF drop<VC> <R15> | 140×90×25 mm | 170 g |
| 1SM-IF drop cable<0.5><R15> |
Multi-function Tools for Cable Termination
(for small-diameter, low-friction indoor optical fiber cable)
This is a special tool for a di. 0.25-mm simplex cable with SM type small-diameter low-friction indoor optical fiber “R 15”, when FA/FSC (field-assembled) connectors are fixed.
[Product code]
P2681009
Specifications
| Cables | Dimensions | Weight (g) |
|---|---|---|
| 1SM-ST indoor <0.25> <R15> | 140×90×25 mm | 170 g |
Multi-function Tools for Cable Termination
This multi-functional tool can perform three functions: it terminates cable ends for fixing field-assembly connectors or FA connectors; it separates a suspension wire from a drop cable(1-fiber type); and it cuts a slit for cicada proof optical drop cables.
[Product code]
P2681038
Specifications
| Cables | Dimensions | Weight (g) |
|---|---|---|
| 1SM-IF drop <C> <R15> | 140×90×25 mm | 230 g |
| 1SM-IF drop <WC> <R15> | ||
| 1SM indoor <0.25> <R15> |
Drop Cable Separator
This tool enables you to easily take out a coated optical fiber from an SM drop cable or SM indoor cable when drawing fibers into individual homes.
[Product code]
P2681029
Applicable cables
→ Can slide sideways
| Types | Width | Thickness | Dial for setting the width of a groove | Lever position of a cable clamp |
|---|---|---|---|---|
| 1-fiber drop optical fiber | Small | Small | Twist off by turning counterclockwise. | L |
| 2-fiber drop optical fiber | Small | Small | Twist off by turning counterclockwise. | L |
| Four-fiber optic aerial drop cable | Large | Small | Twist off by turning clockwise. | L |
| Eight-fiber optic aerial drop cable | Large | Small | Twist off by turning clockwise. | L |
| Four-fiber optic indoor cable (ribbon) | Large | Small | Twist off by turning clockwise. | L |
| Eight-fiber optic indoor cable (ribbon) | Large | Large | Twist off by turning clockwise. | H |
| Eight-fiber optic indoor cable (1-fiber) | Large | Large | Twist off by turning clockwise. | H |
Specifications
| Dimensions | Weight |
|---|---|
| 180×68×17 mm | 250 g |
